Reduced-emission engine technology
2-stroke engine with stratified charge. A fuel-free layer of air is created between the burned charge in the combustion chamber and the fresh charge in the crankcase, reducing the amount of fuel lost during the charge cycle. This results in more power with a lower weight, up to 20% lower fuel consumption than regular 2-stroke engines and significantly reduced exhaust emissions.
Manual fuel pump (Purger)
A small fuel pump delivers fuel to the carburettor at the touch of a button. This reduces the number of starting strokes required following extended breaks in operations.
STIHL ErgoStart (E)
STIHL ErgoStart cuts the effort required to start the tool by half, while the starter cord can be pulled at just one third of the normal force. A coil spring between the starter cord and the crankshaft smoothes out force peaks, making them virtually undetectable through the cord itself.
Simplified starting system
Simply set the choke, pump the fuel primer, pull the starter cord and away you go! The running machine then switches off after a brief press of the stop button. Once the machine is at a standstill, the ignition activates again automatically. Thus the ignition is always ready for starting.
When used in conjunction with a harness, the bike handle enables a smooth mowing action. The bike handle allows the machine to be easily guided, making it ideal for working on large areas and thus reducing fatigue.
For use with loop handle machines.
|Power output hp||1.1|
|Weight kg 1)||5.2|
|Sound pressure level with plastic tool dB(A) 2)||93|
|Sound power level dB(A) 2)||108|
|Vibration value, left with plastic tool m/s2 3)||4.7|
|Vibration value, right with plastic tool m/s2 3)||3.8|
|Total length cm 4)||170|
|Power output kW/bhp||0.8/1.1|
|Cutting diameter mm||420|
|Weight kg 5)||5.2|
|Tank volume l||0.34|
|Standard cutting tool||AutoCut C 26-2|
|Handle type||Tool-free handle adjustment / mower handlebar|
|Anti vibration system||No AV-System|
|Tank cap||STV screw tank cap|
